Display Screen

Type

High-resolution display

Size

7 inches diagonally

Sweep Speed

25mm/sec

Information

Heat rate, lead/pads, alarm on/off, SpO2, AED functions and prompts, alarm selection and limits, delivered energy

Defibrillator

Waveform

Biphasic

Energy Display

Monitor display indicates both selected and delivered energy

Charge Prompt Type

Voice and visual prompts

Electrode Impedance Measurement Range

0~250 ohms

ECG Monitoring

Patient Connection

3-lead ECG cable, or 5-lead ECG cable, paddles

Lead Selection

Displayed on monitor, paddles, I, II, III, AVR, AVL, AVF, V

ECG Size

0.25, 0.5, 1, 1.5, 2, 4 cm/mV display on monitor

Heart Rage

20~300 BPM

Heart Rate Alarm

On/Off displayed on monitor, user-selectable

Smart Alarms

Beeper/voice prompts indicate shockable rhythm

Battery

Type

Rechargeable, Ni-MH battery, 12V

Operating Time

For a new, fully charged battery 60 defibrillator discharges at maximum energy, or 3 hours minimum of continuous ECG monitoring, Additional parameters will effect operating time with different functions

SpO2 Module

Measurement Range

30~100%, ±2% between 80%~90%, others ±5%

Alarm Range

User set high limit and low limit

Alarm Accuracy

±10% within setting values

Alarm Time Accuracy

Less than 12 sec.

Recorder

Paper

50mm thermal

Speed

12.5mm/sec, 25mm/sec, 50mm/sec;

User-selectable 6-second delay

Printing Method

High-resolution, thermal array print head

Print-out Modes

Manual or automatic, user-configurable

On/Off Control

Front panel and paddle

Automatic Function

9-second recording initiated by alarm activation or defibrillator charge or defibrillator discharge

AED Mode

AED Function

Auto analyze and charge X3 with programmable auto energy level selection, scree prompts, and voice prompts

Shockable Rhythms

Ventricular fibrillation

Ventricular tachycardia

QRS complex wave duration

Charge Control

Control on device front panel, press key on paddle

Manual Mode

Energy Selection

Selectable at 2,5, 7, 10, 20, 30, 50, 70, 100, 150, 200, 300, 360 joules

Synchronized Mode

Synchronizes defibrillator pulse to patient’s R-wave.

“ SYNC” message displayed on monitor
